Product Description
Interface:
VIN: Main power input 1.8V-5V.
3-bit pad: I2C bus pull up level, you can choose 1.8V or 3.3V according to the pin master voltage.
SCL: I2C bus clock
SDA: Connected to the I2C bus data
INT: MAX30102 chip interrupt pin
RD: MAX30102 chip's RD LED grounding terminal, generally doesn't need to connect.
IRD: MAX30102 chip's IR LED grounding terminal, generally doesn't need to connect.
GND: grounding wire.
Low Power
Device Drivers
Free Algorithm
Example C Source Code For Arduino And mbed Platforms
Test Data
Competitive Advantages
Highly-integrated, small-size sensor
Non-chest based heart-rate/SpO2 detection
Ultra-low power consumption
Package Included:
2pcs MAX30102 Sensor Module
